My favorite anatomy pictures series #1: Adductor Magnus (to see a fascial release technique for this complex muscle, click here)
Anatomy nerds like me revel in old anatomy books that give you perspective not provided by most modern texts, which have seemingly settled on a particular 2-D point-de-vu about muscle function. This more 3-D one from John Hull Grundy (don’t ask, long out of print, if you can find a copy for under $400, I’ll buy it) whose unique approach makes him a delight and a source of new insight.
One of my favorite muscles (ok, fascia freaks, ‘myofascial unit’) of the moment is adductor magnus. What’s it doing there? Chickens, horses, and bats all get away with having scrawny adductors, but yours fill a generous triangular prism on the inside of your thigh. But we don’t actively adduct a lot, do we? Unless you’re a bull rider, an equestrian, or a member of the world’s oldest profession, what do we need these large and muscular adductors for?
This picture helps answer that question. On the right leg of the picture on the left, you have adductor longus included, going up the pubic bone, but all the rest is just adductor magnus, and I invite you to notice a couple of things that Grundy shows us in these two pictures:
1) Adductor magnus is a twisted sister.
See on the right how adductor magnus has a curved sweep, almost like a the sail on a boat? This twist is rarely seen in two-dimensional anatomy texts, but it is crucial to understanding this balancing muscle’s function. This twist is the result of the medial rotation of the femur in foetal development. Our legs start out growing to the side, like a fish fin or an alligator leg, and rotate inward during development, and turn further inward as we stand and walk. Look at how the ligaments are on the hip and you’ll see the same twist.
The twist in the adductor magnus allows it to be a major stabilizer of the pelvis. Let’s say you bend down to pick up your child (or a bag of groceries, whichever needs tending to first), the large muscles on the front, side, and back of your pelvis are doing the major work – while adductor magnus prevents the synergistic actions of these muscles that would throw you off balance. It is uniquely positioned to put the damper on flexion or extension, medial or lateral rotation, side-to-side sway, and, of course, abduction.
Adductor magnus is in a central position. It’s squarish shape and its twisted nature makes it a major pelvic stabilizer – one many therapists and trainers ignore.
Anatomy Trains, 3rd edition, now in ebook format! The brand new Anatomy Trains book maps the longitudinal myofascial connections – how the muscles are functionally linked in ‘myofascial meridians’ through the fascial webbing. Anatomy Trains opens a unique window to the anatomy of connection via this book – fully illustrated in 4-color with new anatomy art, fascial… Read moreRead more
2) Adductor magnus comes in three parts.
Best seen in the left leg of the left hand picture, it’s worthwhile mental separating adductor magnus into three parts.
a) The uppermost part (sometimes named adductor minimus – even though there is no real fascial separation from the rest of the muscle, this upper part is innervated by the obturator nerve, the rest of it by the sciatic) runs from somewhat forward on the pubic part of the ramus down and back to the linea aspera of the femur. This configuration makes this part an anterior tilter of the pelvis (hip flexor), and a lateral rotator (or, as implied above, a resistor of medial rotation and posterior pelvic tilt).
b) The middle part, majorly shown in both pictures, comes from farther back on the ischial part of the ramus and goes down the middle part of the linea aspera. By itself it acts to stabilize rotation of the femur (maybe acting as a medial rotator), but it also acts as part of the ‘4th hamstring’, combining with the short head of biceps femoris, as in this picture from Anatomy Trains,. Only the middle part of adductor magnus is pictured on the right side of the illustration, coupled with the short head of biceps, which overlaps considerably with that part of adductor magnus. The long head of biceps – a two-joint muscle – is shown on the left. The middle part of adductor magnus and the short head of biceps make this ‘4th hamstring’ – if you’re having trouble getting the results you want from the three two-jointed hamstrings, try the appropriate part of the two single joint muscles that lie underlie the multiple-joint hamstrings. (The technique for the short head of biceps femoris is on our Spiral Line technique DVD.)
c) The longest part of adductor magnus is also like a ‘one-joint hamstring’, but that is the hardest part to see clearly here in these front views. As you can see in this view from the rear (again, from Anatomy Trains), that longest part is again almost a separate muscle, with fibers going straight down from the ischial tuberosity like the hamstrings, but fastening firmly into the medial epicondyle of the femur you can feel just above the inside of your knee. This part of adductor magnus definitely keeps the pelvis and the upper body from falling forward – and as a muscle crossing only the hip, can do so much more efficiently the the the 2-jointed hamstrings.
Long story short: we should use this adductor as a stabilizer, and the hamstrings as motivators, but for far too many people, the hamstrings get appropriated as postural stabilizers, and are therefore waaaaay too short.
Now, you could look all this up in a second if only you had the e-book edition of Anatomy Trains or you can get the full video of some techniques for it here.
